HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L
HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L view 1 HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L view 2 HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L view 3 HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L view 4 HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L view 5 HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L view 6

HX55 3590044 Turbo charger fit for 1994-2011 Cummins M11 M-Series Engine 10.8L

★★★★★ No reviews yet
$189.00
In stock — 16 unit(s) in our U.S. warehouse, ships within 1 business day.
Buy it now
Purchase without worry Domestic U.S. shipment — 3 to 5 business days to your door. No customs clearance, no import duty, no hidden tax. 30-day returns.
Free ShippingFrom our U.S. warehouse — 3–5 day delivery, no customs.
Secure PaymentEncrypted checkout. Guest checkout, no account needed.
24/7 SupportReach our help center by email any time you need.
Easy ReturnsChanged your mind? Send it back within 30 days.
HX55W Turbo Turbocharger 359044 fit for Dodge Cummins M11 1994-2001

Application:
fit for Cummins Truck, Bus with ISM, ISME, M11 Engine 2007-2012
fit for Cummins Truck Bus, Truck Delta Alpha Plus with M11 Engine 1999-2009

Engine: fit for Cummins Diesel Engine ISM / ISME / M11 L10 10.8L

Interchange Part Number:
3590044, 3590045, 3803938,2480262
3536995, 3536996, 3800471 ,2834364,
4039173, 4046031, ​​​2834419
3536149, 800471, 3800471RX

3593604, 3593601, 3593602, 3593604H
4024965, 4024966, 4024966RX,3593603

Product Specific:

Compressor:
Trim: 0.70
A/R: 0.68
IND: 62.90
EXD: 97.80
Turbine:
Trim: 0. 93
A/R: .88
IND: 86.40
EXD: 77.80

Thread specification: M16 x 18.56

Diameter of oil return hole: 20 MM

Turbo Model: HX55
Engine: M11, ISM, ISME 380 20, B5.9-C, ISME Euro-2 & Euro-3
Displacement: 11.0L, 1100 ccm
Cooling Type: Oil Cooling
Bearing Type: Journal Bearing / Floating Bearing
Thrust bearing: 270 Degrees
Hosepower: Up to 500HP
Condition: Brand New
Accessories: You will get exactly as shown in the picture above
Package Size: 34x 31 x 29 cm
Package Weight: 17680 g

Feature:

* Product Material
1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing: ZL104 aluminum with lightweight
4. Compressor wheel/blades: Cast aluminium blades – superior air tightness & corrosion resistance

* Product Feature:
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer

NOTE:
* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!

a. Notice
1. California Prop 65 Warning
2. Authority ID：MXR02FXSY（Very important, please do not delete）
